Silo Top Bag Filter

A Silo Top Bag Filter(also called silo vent bag filter or silo top dust collector)is a compact,pulse-jet operated dust filtration unit installed directly on the top of powder/storage silos.It cleans dust-laden air displaced during pneumatic filling or material charging,retains valuable powder inside the silo,and discharges clean air to atmosphere.

Working Principle

Dust-laden air in:When the silo is filled pneumatically,the displaced air with fine dust flows upward into the filter housing.

Filtration:Air passes through filter bags/cartridges;dust particles are trapped on the outer surface,while clean air goes through.

Pulse-jet cleaning:At set intervals,a pulse jet system fires short bursts of compressed air backward through the bags.This dislodges the dust cake,which falls back into the silo.

Clean air discharge:Purified air exits the filter vent,meeting environmental emission standards.

Main Structure

Stainless steel body:Usually 304/316 stainless steel,compact cylindrical design with bottom flange for silo-top mounting.

Filter elements:High-efficiency polyester/POLYPLEAT®filter bags or pleated cartridges;optional PTFE membrane for fine/sticky dust.

Pulse jet cleaning system:Solenoid valves,air manifold,pressure gauge,and timer/controller for automatic cleaning.

Weatherproof cover:Hinged,lockable top cover protects components from rain/dust;easy access for maintenance.

Accessories:Pressure differential gauge,condensate drain valve,safety switches.

Key Features&Advantages

High efficiency:Up to 90%filtration;emission concentration≤10–30 mg/Nm³,meets strict environmental regulations.

Compact&space-saving:Small footprint,low profile;ideal for limited silo-top space.

Easy installation:Bolt-on flange connection;no complex ductwork required.

Low maintenance:Tool-free filter replacement;one person can change bags in minutes.

Automatic operation:Self-cleaning pulse jet system runs on timer or differential pressure;minimal manual intervention.

Durable build:Stainless steel housing+robust filter media;long service life even in harsh conditions.

Material recovery:Collected dust drops back into the silo,reducing waste and saving raw material costs.
